Every minute is vital when your time is money. At any point, you have decisions to make, issues to handle, opportunities to check. Xpert UPS is your ultimate choice.
| MODEL | EX-1000 |
|---|---|
| INPUT | |
| Voltage | 166-276V AC (Bi.Volt) |
| Fraquency | 50-60Hz (Auto Sensing) |
| OUTPUT | |
| Voltage | 220V AC ± 10% |
| Frequency | 50-60Hz ± 1Hz |
| Capacity | 1000VA |
| Power Factor | 0.7/0.8 |
| Waveform | Simulated Sine Wave |
| Crest Factor | 3:1 |
| Transfer Time | 2-4MS Max 9MS |
| BATTERY | |
| DC Voltage | 12V DC |
| Type | Lead Acid VRLA Type |
| Configuration | 12V/7AH x 1 |
| Typical Recharge Time | 4 hours (to 80-90%) |
| Back-up time | 7-18Mins(APPOX.) |
| Transformer | E Transformer |
| PROTECTION | |
| Full Protection | Overload AC Mode >100% input fuse blown, Overload inverter Shutdown, Short Circuit: Shutdown instantly |
| Enviroment | |
| Humidity | 20-90% RH Max. (Non-condensing) |
| Noise Level | 45dB (1 Meter) |
| Temperature | 0~40°C |
| Alarm | |
| Battery Mode | Beeps |
| Interface | |
| Interface | USB/RS232 (Optional) |
| Platforms | Microsoft Windows Linux/Max etc. |
